品牌

Brand

苏华特

SUHUATE

型号

Type

SHT2561

外形尺寸 长*宽*高(mm)

Size Length * Width * Height (mm)

1980mmX730mmX1150mm

电 器 系统

  Electrical system

控制器规格

Controller specification

72V4000W专用智能化控制器；无级调速，制动断电，欠压保护，过流保护等性能，稳定。72V 控制器，强劲快速，自动修复。

72V4000W  intelligent control system; Stepless speed regulation, braking power off, undervoltage protection, overcurrent protection and other performance, stable. 72V controller, powerful, fast, automatic repair.

电池

Battery

72V 30Ah 大容量磷酸铁锂电池，国内一线品牌锂电池，BMS参数根据4000W电机和4000W控制器匹配的参数进行设定

72V 30Ah large capacity lithium iron phosphate battery, domestic first-line brand lithium battery, BMS parameters are set according to 4000W motor and 4000W controller matching parameters

可同时安装两组72V30Ah磷酸铁锂电池

Two 72V30Ah lithium iron phosphate batteries can be installed at the same time

电机规格

Rating of machine

14寸，4000W直流永磁

14 inch, 4000W DC permanent magnet

电机额定输出功率

Rated output power of motor

4000W

电路系统

Circuit system

全车防水、阻燃插件，骑行更安全

Whole waterproof, flame retardant plug-in, more safe riding

充电器

Charger

72V 锂电充电器，耐用、安全、充电平稳、耐高温

72V lithium charger, durable, safe, stable charging, high temperature resistance

充电时间

Charging time

2-4小时

2-4 hours

充电使用电源

Power supply for charging

220V-50HZ

车 身 配 置

    Body matching

车体

Body

钢制车架+塑料外壳

Steel frame + plastic shell

仪表

Instrument panel

LED

灯具

Luminaire

LED

转向灯

Turn signal

LED

车架

Frame

锂电专用车架，高强度钢结构件；整车采用大踏板，前后避震，结构硬朗、扎实、稳定。

Lithium battery special frame; The whole vehicle adopts large pedal, front and rear shock absorber, the structure is strong, solid and stable.

前叉

Front fork

液压带阻尼无缝管材质，外加塑料防护套

Hydraulic belt damped seamless tube material, plus plastic protective jacket

灯光及信号

Lights and signals

透镜LED大灯，前照灯，前左、右转向灯：组合后尾灯，配置左、右转向灯。电喇叭；凌厉霸气的水晶的前大灯，按照仿生学原理设计，外形更美观，照明更安全

Lens LED headlights, headlights, front left and right turn signals: combined rear taillights, equipped with left and right turn signals. Electric horn; The crystal headlights are designed according to the principle of bionics, which makes the appearance more beautiful and the lighting more safe

遥控器及防盗器

Remote control unit and burglar alarm

配置智能化遥控器，智能化防盗器

Intelligent remote control, intelligent anti-theft device

减震器规格（前/后）

Shock absorber Specifications (front/rear)

前、后液压减震；前后全液压，后双减震

Front and rear hydraulic shock absorption; Full hydraulic front and rear, dual shock absorption rear

底 盘   Bottom plate

动力传动系统

Power transmission system

无级调速系统

Stepless speed control system

驱动系统

Drive system

后轴驱动

Rear axle drive

制动型式（前/后）

Brake type (front/rear)

碟刹，220mm刹盘

Disc brake, 220mm brake disc

制动方式（前/后）

Braking mode (front/rear)

碟刹/碟刹

Disc brake/Disc brake

前后轮轴距

Front and rear wheelbases

1440mm

轮胎规格（前/后）

Tire Specifications (front/rear)

前16寸后14寸

16 inches front, 14 inches back

前100/80/16   后：110/80/14

First 100/80/16 Post: 110/80/14

制动距离

Braking distance

≤6.5 m

最大行驶速度

Maximum travel speed

≥100km/h

续驶里程

Range

≥150km

最大爬坡度

Maximum gradient

≥12°

充电输入电压

Charge input voltage

220v

欠压保护值

Undervoltage protection value

51.5±0.5V

定制线路，快递专用

Customized lines, express only

可带IOT手机远程操控

Remote control with IOT mobile phone

加强型底座，载货专用

Reinforced base, special for cargo
