品牌

Brand

苏华特

型号

Type

SHT2491

电 器 系 统

电控

Electric control

48V智能化控制系统；无级调速，制动断电，欠压保护，过流保护等性能，稳定。48V 12管 控制器，强劲快速。

48V intelligent control system; It has stable performance features such as stepless speed regulation, power cut-off during braking, under-voltage protection, over-current protection, etc. A 48V 9-tube controller provides strong and rapid performance.

电池

Battery

48V 20AH,  大容量深循环铅酸蓄电池，品牌超威电池，全国联保。

48V 20AH, high-capacity deep-cycle lead-acid battery. The brand is Chaowei Battery, and it comes with nationwide warranty service.

电机

Motor

48V 500W  电机；超大功率满盘电机，动力持久强劲，爬坡能力，载重能力强。

48V 500W motor; It is a super high-power full-disc motor, offering lasting and powerful performance, with strong climbing ability and high load-bearing capacity.

充电器

Charger

48V  充电平稳、耐高温

With 72V, the charging process is stable and it can withstand high temperatures.

充电时间

Charging time

7-9小时

7-9hours

音响

Audio system

电喇叭；警用巡逻扬声器，声音响亮；高科技内置隐藏式喊话器系统，安全、美观、大方。

Electric horn; Police patrol speaker with a loud sound; High-tech built-in hidden public address system, which is safe, aesthetically pleasing and elegant.

车 身 配 置

颜色

Color

高级灰色标准色，客户可定制

Color:Advanced gray standard color, which can be customized by customers.

座椅

Seat

整体式海绵外包皮革座椅，舒适耐用。

Seat: Integrated sponge seat covered with leather, which is comfortable and durable.

车体

Body

钢制车架+塑料外壳

Steel frame + plastic shell

仪表台

Dashboard

多功能液晶数码仪表盘，功能齐全

Dashboard: Multi - function LCD digital instrument panel with complete functions.

车架

微型车车架，高强度钢结构件；整车采用大踏板，前后避震；搭配加固型大货架，结构硬朗、扎实、稳定。保险杠、固定警灯警具专用巡逻警车保险杠，采用一次成型模具，6级电镀精工制造，耐腐蚀，经久耐用，光泽度好，美观漂亮，实用。

The frame is of a micro-car type, made of high-strength steel structural parts. The whole vehicle is equipped with a large pedal and front and rear shock absorbers. It is matched with a reinforced large rack, featuring a tough, solid and stable structure.

The bumper is a special patrol police car bumper for fixing police lights and equipment. It is made by a one-time molding die and manufactured with 6-level electroplating technology. It is corrosion-resistant, durable, has good gloss, looks beautiful and is practical.

灯光及信号

Lights and signals

前照灯，前后转向灯，组合后尾灯，电喇叭；凌厉霸气的水晶的前大灯，按照仿生学原理设计，外形更美观，照明更安全

Headlights, front and rear turn signals, combined rear taillights, and an electric horn. The sharp and imposing crystal headlights are designed in accordance with the principles of bionics, featuring a more aesthetically pleasing appearance and ensuring safer illumination.

后视镜

Rearview mirrors

左右各一手动型外后视镜

Rearview mirrors: One manual external rearview mirror on each of the left and right sides.

底     盘

动力传动系统

Power transmission system

无级调速系统

Stepless speed control system

驱动系统

Drive system

后轴驱动

Rear axle drive

制动系统

Brake system

前碟刹,后鼓刹，性能优越

Front disc brakes and rear drum brakes, with superior performance.

轮胎

Tyre

3.0-10 轮胎，耐磨防刺穿，品牌真空轮胎

3.0-10 tires, wear-resistant and puncture-proof, branded tubeless tires.

外形尺寸 长*宽*高(mm)

Overall dimensions (Length×Width×Height, in mm)

1995×680×1280 mm

整车装备质量

Vehicle curb weight

110kg

整车载荷

Vehicle load-carrying capacity

160kg

轴距

Wheelbase

1350 mm

额定乘员

Rated passenger capacity

2人（含驾驶员）

 2 persons (including the driver).

初速30km/h制动距离

Braking distance at an initial speed of 30km/h

≤6.5 m

最大行驶速度

Maximum driving speed

≤43km/h

续驶里程

Range

≤45Km

最大爬坡度

Maximum gradability

≤20%

Maximum gradability: ≤20%

充电输入电压

Charging input voltage

220v

Charging input voltage: 220V
