品牌

Brand

苏华特

SUHUATE

型号

Type

TDT093Z

电 器 系 统   Electrical system

电控

Electric control

48V 智能化控制系统

60V 智能化控制系统

72V 智能化控制系统

48V intelligent control system

60V intelligent control system

72V intelligent control system

电池

Battery

48V 20Ah 铅酸电池

60V 20Ah 铅酸电池

72V 20Ah 铅酸电池

48V 20Ah lead-acid battery

60V 20Ah lead-acid battery

72V 20Ah lead-acid battery

电机

Motor

48V 500W 高效电机

60V 500W 高效电机

72V 500W 高效电机

48V 500W high efficiency motor

60V 500W high efficiency motor

72V 500W high efficiency motor

电路系统

Circuit system

全车防水、阻燃插件，骑行更安全

Whole waterproof, flame retardant plug-in, more safe riding

充电器

Charger

铅酸充电器，耐用、安全、充电平稳、耐高温

Lead-acid charger, durable, safe, stable charging, high temperature resistance

充电时间

Charging time

6-8小时

6-8 hours

车 身 配 置   Body matching

车体

Body

钢制车架+塑料外壳

Steel frame + plastic shell

仪表

Instrument panel

多功能黑莓全面屏数码仪表盘，功能齐全

Multifunctional blackberry Full screen digital dashboard, full of features

车架

Frame

铅酸专用车架，高强度钢结构件；整车采用大踏板，前后避震，结构硬朗、扎实、稳定。

Lead-acid battery special frame; The whole vehicle adopts large pedal, front and rear shock absorber, the structure is strong, solid and stable.

前叉

Front fork

液压带阻尼无缝管材质，外加塑料防护套

Hydraulic belt damped seamless tube material, plus plastic protective jacket

灯光及信号

Lights and signals

透镜LED大灯，前照灯，前左、右转向灯：组合后尾灯，配置左、右转向灯。电喇叭；凌厉霸气的水晶的前大灯，按照仿生学原理设计，外形更美观，照明更安全

Lens LED headlights, headlights, front left and right turn signals: combined rear taillights, equipped with left and right turn signals. Electric horn; The crystal headlights are designed according to the principle of bionics, which makes the appearance more beautiful and the lighting more safe

遥控器及防盗器

Remote control unit and burglar alarm

配置智能化遥控器，智能化防盗器

Intelligent remote control, intelligent anti-theft device

前减震

Front shock absorber

无缝，阻尼，双管液压

Seamless, damped, dual hydraulic

后减震

Rear shock absorber

倒置结构，带阻尼

Inverted structure with damping

底 盘   Bottom plate

动力传动系统

Power transmission system

无级调速系统

Stepless speed control system

驱动系统

Drive system

后轴驱动

Rear axle drive

制动系统

Brake system

前碟刹,后鼓刹，性能优越

Front disc brake, rear drum brake, superior performance

外形尺寸 长*宽*高(mm)

Size Length * Width * Height (mm)

1760mm×675mm×1090mm

轴距

Wheelbase

1250mm

轮胎

Tyre

3.0-10 真空轮胎

3.0-10 vacuum tires

制动距离

Braking distance

≤6.5 m

最大行驶速度

Maximum travel speed

≤43km/h

续驶里程

Range

48V 20Ah 铅酸电池

48V 20Ah lead-acid battery

≤50Km

60V 20Ah 铅酸电池

60V 20Ah lead-acid battery

≤60Km

72V 20Ah 铅酸电池

72V 20Ah lead-acid battery

≤70Km

最大爬坡度

Maximum gradient

≤18°

充电输入电压

Charge input voltage

220v
