品牌

Brand

苏华特

型号

Type

TDT093Z

电 器 系 统

电控

Electric control

48V智能化控制系统；无级调速，制动断电，欠压保护，过流保护等性能，稳定。48V 9管 控制器，强劲快速，自动修复。

48V intelligent control system; It has the performances such as steples speed regulation, power-off braking, undervoltage protection, overcurrent protection, etc., and features stable operation. The 48V 9-tube controller is powerful and fast, and it has the function of automatic repair.

电池

Battery

48V 40Ah 天能大容量磷酸铁锂电池，全国联保。

48V 40Ah Tianneng large-capacity lithium battery, guaranteed nationwide.

电机

Motor

48V 1500W  永磁直流无刷电机；高效电机，动力强劲，高效节能，续航里程长。

48V 1500W permanent magnet DC brushless motor; It is an efficient motor with strong power, high efficiency and energy conservation, and it can provide a long driving range.

电路系统Circuit system

全车防水、阻燃插件，骑行更安全

Circuit system: The entire vehicle is equipped with waterproof and flame-retardant connectors, making the ride safer.

充电器charger

48V40Ah 锂电充电器，耐用、安全、充电平稳、耐高温

48V 40Ah lithium battery charger, durable, safe, with stable charging performance and resistant to high temperatures.

充电时间Charging time

6-8小时

Charging time: 6 - 8 hours

车 身 配 置

车体

Body

钢制车架+塑料外壳；

Vehicle body: Steel frame + plastic shell

仪表

Instrument panel

多功能黑莓全面屏数码仪表盘，功能齐全

Instrument: Multifunctional blackberry full-screen digital instrument panel, which is fully featured.

车架

Frame

锂电车车架，高强度钢结构件；整车采用大踏板，前后避震，结构硬朗、扎实、稳定。

The frame of the lithium-powered electric bicycle is made of high-strength steel structural components. The whole vehicle is equipped with a large pedal, front and rear shock absorbers, and features a tough, solid and stable structure.

前叉

Front fork

液压带阻尼无缝管材质，外加塑料防护套

Front fork: Made of seamless tube material with hydraulic damping, and equipped with a plastic protective sleeve.

灯光及信号

Lights and signals

透镜LED大灯，前照灯，前左、右转向灯：组合后尾灯，配置左、右转向灯。电喇叭；凌厉霸气的水晶的前大灯，按照仿生学原理设计，外形更美观，照明更安全

Lens LED headlight, front headlight, front left and right turn signals: combined rear tail lights with left and right turn signals configured. Electric horn; The sharp and imposing crystal front headlight is designed according to the principles of bionics, which makes it more aesthetically pleasing in appearance and safer in illumination.

P档

P gear

点动式开关，车辆启动更安全

P gear: It is a jog-type switch, making the vehicle start more safely.

遥控器

防盗器

Remote controller and anti-theft device

配置智能化遥控器，智能化防盗器

Remote controller and anti-theft device: Equipped with an intelligent remote controller and an intelligent anti-theft device.

前减震

Front shock absorbe

无缝，阻尼，双管液压

Front shock absorber: seamless, damping, double-tube hydraulic。

后减震

Rear shock absorber

倒置结构，带阻尼

Rear shock absorber: Inverted structure, with damping.

车尾箱

Rear trunk

外卖专用框

Rear trunk: Special frame for food delivery

底     盘

动力传动系统

Power transmission syste

无级调速系统

Power transmission system: Stepless speed regulation system

驱动系统

Drive system

后轴驱动

Drive system: Rear axle drive

制动系统

Braking system

前碟刹,后碟刹，性能优越

Braking system:Front disc brake and rear disc brake, with superior performance.

外形尺寸 长*宽*高(mm)

Overall dimensions (Length×Width×Height, inmm)

1760mm×675mm×1090mm

Overall dimensions (Length×Width×Height, inmm):

1760mm×675mm×1090mm

轴距

Wheelbase

1250mm

Wheelbase:1250mm

轮胎

Tire

3.0-10 真空轮胎

Tire: 3.0 - 10 tubeless tire

额定乘员

Rated passenger capacity

1人

Rated passenger capacity: 1 person

制动距离

Braking distance

≤6.5 m

Braking distance: ≤6.5 m

最大行驶速度

Maximum driving speed

≤63km/h

Maximum driving speed: ≤63km/h

续驶里程

Range

≤80Km

Range: ≤80 km

最大爬坡度

Maximum gradability

≤20%

Maximum gradability: ≤20%

充电输入电压

Charging input voltage

220v

Charging input voltage: 220V
