品牌Brand

苏华特SUHUATE

型号Type

炫铠一号，SHT2571

Xuankai No.1  SHT2571

电 器 系 统   Electrical system

电控

Electric control

72V 智能化控制系统；无级调速 ，制动断电 ，欠压保护 ，过 流保护等性能 ，稳定。72V 12 管 控制器 ，强劲快速。

72V intelligent control system;  It  has stable performance features such as stepless speed regulation, power cut-off during braking,

under-voltage protection, over-current protection, etc. A 72V  12-tube controller provides strong and rapid performance.

锂电池

Lithium battery

72V 150Ah 三元锂电池

72V 150Ah Ternary lithium battery

电机Motor

ANANDA17寸5000W   电机；超大功率满盘电机 ，动力持久强劲， 爬坡能力 ，载重能力强。

ANANDA17寸5000W motor; It is a super high-power full-disc motor, offering lasting and powerful performance,   with strong climbing ability and high load-bearing   capacity.

充电器

Charger

72V 充电平稳、耐高温

With 72V, the charging process is stable and it can withstand high temperatures.

充电时间

Charging time

7-9 小时  7-9hours

音响

Audio system

电喇叭Electric horn

车 身 配 置   Body matching

颜色

Color

高级灰色标准色 ，客户可定制

Color:Advanced gray standard color, which can be customized by customers.

座椅

Seat

770mm整体式海绵外包皮革座椅 ，舒适耐用。

Seat: 770mmIntegrated sponge seat covered with leather, which is comfortable and durable.

车体

Body

钢制车架+塑料外壳

Steel frame  + plastic shell

仪表台

Dashboard

多功能液晶数码仪表盘 ，功能齐全

Dashboard: Multi - function LCD digital instrument panel with complete functions.

车架

Frame

微型车车架，高强度钢结构件.

The frame is of a micro-car type, made of   high

-strength steel structural  parts.

灯光及信号

Lights and signals

前照灯 ，前后转向灯 ，组合后尾灯 ，电喇叭；凌厉霸气的水 晶的前大灯 ，按照仿生学原理设计 ，外形更美观 ，照明更安 全

Headlights, front and rear turn signals, combined rear   taillights, and an electric horn. The sharp and imposing crystal headlights are designed in accordance with the  principles of bionics, featuring a  more aesthetically

pleasing appearance and ensuring safer illumination.

后视镜Rearview mirrors

左右各一手动型外后视镜

Rearview mirrors: One manual external rearview mirror on each of the left and right sides.

底 盘   Bottom plate

动力传动系统Power transmission system

无级调速系统 Stepless speed control system

驱动系统Drive system

后轴驱动 Rear axle drive

制动系统Brake system

前后双碟刹，采用摩托车级别工艺，双后减，性能优越

Front and rear double disc brakes, using motorcycle-level craftsmanship, double rear shock absorbers, superior performance.

轮胎Tyre

前轮：3.0-12   后轮3.0-10 ，耐磨防刺穿 ，品牌真空轮胎

Front tire: 3.0-12

Rear tire: 3.0-10

Wear-resistant and puncture-proof

Brand vacuum tire

外形尺寸 长*宽*高(mm)

Size Length * Width * Height (mm)

2150×360×1140 mm

整车装备质量

Vehicle curb weight

96kg

整车载荷

Vehicle load-carrying capacity

≤300kg

轴距

Wheelbase

1460 mm

额定乘员

Rated passenger capacity

2 人（含驾驶员）

2 persons (including the driver).

初速 30km/h 制动距离    Braking distance at an  initial speed of 30km/h

≤6.5 m

最大行驶速度Maximum travel speed

≤85km/h

续驶里程Range

≤    Km

最大爬坡度Maximum gradient

≤20%

Maximum gradability:  ≤20%

充电输入电压Charge input voltage

220v

Charging input voltage: 220V
